CNC turned parts

3 个评论 since 17.01.2024
商品信息 "CNC turned parts"

We have been manufacturing turned and milled parts since 1967. Qualified personnel with many years of manufacturing expertise and smart ideas, together with high-performance machines and innovative tool concepts, guarantee top-quality products that offer excellent value for money. Flexible structures ensure trouble-free adaptations for practically all process steps. In this way, we can examine your own individual needs in order to find the right solution.

We will work together with you to define the specific conditions and constraints for the required CNC turned parts and then plan and implement their manufacture. Every custom part, whether it is a lathed rod or a screw machine part, passes through our stringent end-to-end QM system. In addition, our experts are present throughout the entire process chain to offer added reliability. Thanks to these measures, we deliver your precision turned parts quickly and absolutely reliably. So when can we use our machining skills for you?

Range of services for custom CNC turned parts (extract)


Machining range
  • Round Ø 4 mm up to Ø 65 mm
  • Length von 5 mm up to 350 mm
  • Small, medium and large batches
Machining capabilities/options
  • Cross holes
  • Grooves
  • Milled sections
  • Polygon turning
  • Spanner surface
  • Internal hexagon
  • Thread types:
    • metric or inch thread
    • regular, fine-pitch and left hand thread
  • Complicated geometries
  • Custom marking
Material
  • Undercut steel
  • Stainless steel A2 quality
  • Stainless steel A4 quality
  • Other steels that are particularly corrosion-resistant, salt water-resistant or heat-resistant, as well as high-tensile steels
Surface
  • Coating
    • electroplated galvanised
    • Special surface
  • Treatment
    • free of grease
    • defined oil film
  • Finishing
    • Grinding
    • Tempering
    • Nitrocarburizing
