SL 固定器
for bolts and shafts with groove; compensating for play
19 个评论 since 21.06.2021
欲查找所需货品，您可任选不同筛选标准 ，或在表格顶部搜索文本或文本和货号 。
欲再次取消筛选器设置，请单击表格下方的“清空”按钮。
欲显示产品详细信息和 3D 模型，可单击与所需货品对应的行。
欲再次取消筛选器设置，请单击表格下方的“清空”按钮。
欲显示产品详细信息和 3D 模型，可单击与所需货品对应的行。
商品信息 "SL 固定器"
SL-retainer
SL-retainers are retaining elements made from spring band steel for bolts, axles and shafts with slot or groove and prevent axial detachment. It is possible to mount the retainers either with or without an assembly tool. They can be disassembled again without great effort.
Sizes for shaft diameters 4 mm to 16 mm are available as standard.
Frequently Asked Questions (FAQ)
What are SL-retainers?
SL-retainers made of spring band steel are retainers that prevent shafts, axles, and bolts with groove from being pulled axially out of their position.
What are the advantages of SL-retainers?
Simple assembly, reusability, play-compensating properties as well as reliability and stability in various applications. Compared to other retaining elements, they offer increased safety through a tab that encloses the bolt end, providing additional security against axial pull-out.
What materials are used for SL-retainers?
SL-retainers are made from high-quality spring band steel, which exhibits excellent spring force and durability.
For which shaft diameters are SL-retainers available?
SL-retainers are available for shaft diameters from 4 mm to 16 mm.
In which industries are SL-retainers used?
They are used, for example, in mechanical engineering, automotive engineering, materials handling, packaging technology, medical technology, and in general mechanics.
Do I need a special tool for assembly?
SL-retainers can be installed with or without special assembly tool, with the use of a tool being recommended.
What surface coating do SL-retainers have?
The surface coating is either electr. galvanised white or phosphated oiled.
How does the play-compensating property of SL-retainers ensure secure hold?
They compensate for tolerances and irregularities to prevent unwanted movements, thereby increasing the reliability and stability of the connection.
Are SL-retainers reusable?
Yes, they can be easily removed and reused, leading to cost savings.
What standards apply to SL-retainers?
They refer to standards such as DIN 6799, which defines dimensions and requirements for locking washers.
What should be considered when assembling SL-retainers?
The components should be clean, the correct size should be chosen, and excessive force should be avoided.
Why is the use of high-quality materials important for SL-retainers?
High-quality spring band steel ensures durability, high spring force, and resilience in demanding applications.
